DEKO OC
DEKO OCEAN GD B15 SLIDING DOORS
GD B15 aluminium glazed sliding doors are the world’s probably lightest fire classified glazed door systems for cruise ships, ferries, and luxury yachts.
-
B 15
Fire resistance
-
30-35dB2
Max Frame size
-
74mm
Profile size
DEKO OC
DEKO OCEAN GD B15 SLIDING DOORS
GD B15 aluminium glazed sliding doors are the world’s probably lightest fire classified glazed door systems for cruise ships, ferries, and luxury yachts.
The doors are fire tested and classified according to the latest FTP CODE standards set by the International Maritime Organization (IMO).
A COMPLETE DOOR SYSTEM
Developed as a complete system, the doors are designed to compliment the design of the vessel’s steel bulkhead and partitions. DEKO Ocean GD B15 sliding doors are available as single or double and can be built into GP B15 partitions and other types of partitions. DEKO Ocean GD B15 sliding doors have been fire tested at internationally recognized and accredited fire institutes and certified by Bureau Veritas.
APPLICATION
DEKO Ocean GD B15 sliding doors can be furnished with various high quality marine-type hardware and accessories. The doors can be supplied as manual, self-closing, and automatic. The GD B15 self-closing doors are using spring and damper device to close the door smooth and automatically without any electricity required. Custom-made designs are available on request.
NARROWER AND LIGHTER
The doors are an integrated part of the DEKO Ocean partition concept that is up to 25% narrower and 25% lighter than most of the other
competing systems on the market today.
COLOURS AND SURFACE FINISHES
GD B15 sliding doors are supplied powder coated in RAL colors as standard. Anodised finishes are also available. In addition, the profiles can be supplied with special surface finishes such as copper look, stainless steel look etc.
DEKO OC
GD B15 SLIDING D
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla urna massa, ultricies sed vehicula quis, feugiat eu turpis. Curabitur convallis, metus vel finibus vehicula, ipsum lectus bibendum massa, non congue arcu tellus ac erat. Vivamus mattis sed quam quis consectetur. Nunc eu dapibus justo, id semper dolor.
01
Interdum et malesuada
Sed lacinia metus et arcu cursus ultricies. Fusce eu aliquet nibh. Cras sit amet rhoncus neque. Integer rhoncus tortor sed justo pulvinar cond.
02
Morbi eget risus
Morbi sit amet orci et nibh laoreet hendrerit in in elit. Etiam volutpat ex nulla, pretium tempor elit molestie ut. Integer blandit interdum risus id semper nulla mattis purus quis felis.
A COMPLETE DOOR SYSTEM
| Type | Fire resistance | Door leaf thickness | Door weight | Glass weight (m2) |
| Double slidi ng door | B15 | 74mm | 116kg1 | 31kg |
| Type | Max. door frame size | Max. door leaf size | Sound insulation (Rw) |
| Double slidi ng door | 2439*2912mm3 | 1232*2904mm3 | 30-35dB2 |
-
01
Standard door size (frame): 2000*2000*74.
-
02
The airborne sound insulation of sliding door depends, among other things, on the glasstype installed and door sill.
Please be aware that drop sealant can be delivered in various solutions and door stops are available on request. -
03
Available to marginally enlarge: (width, height)<15%; surface area<10%
